If your unsure what to purchase but wish to start learning about the Luxeon LED modules, then try our Luxeon LED Starter Kit.

The kit comes with your choice of:
1 - Watt Luxeon Star LED module, you pick color.
1 - Small Heatsink with self-stick backing.
1 - Micro-2004 Driver and connection cable.
1 -"AA" Battery Holder, and Instructions.

Luxeon LED's available in
Red, Green, Blue, White Modules

.....................Kit Instructions

( "AA" Battery not included )

Build your own animatronic talking character from the supplied kit.

With this kit you can build a character that will have a moving jaw that is controlled from any 1 volt peak to peak sound input, such as from a CD player, microphone, stereo source. ( 1 volt line level required )

Kit includes:
Standard R/C servo.
Servo linkage hardware kit.
.. ( Note: Hardware may vary from image shown, as new items are made available)
3D Printed PLA- Plastic Servo mounting bracket, support and hardware
Ball and Joint connectors( 4-40 size).
Threaded Rod (4-40 size 12" long).
AutoTalker E servo controller.
AutoTalker controller instruction manual.
9 Vdc regulated power supply (wall type)

( Requires audio source, CD player, Stereo, Mask, Character not included )

Optional Colors Available
for Brackets / Components

With this kit you get a heavy duty servo, bracket nd components to connect the servo up as a mechanical motion linkage unit.

Kit includes:
3D Printed PLA- Plastic Servo mounting bracket, support and hardware
Ball and Joint connectors( 4-40 size).
Threaded Rod (4-40 size 12" long).
Heavy Duty Standard Servo
Servo Mounting Hardware ( Screws, Brass inserts, grommets )
Universal Servo Mount.

Servo Linkage Applications, Guide

( Note: Hardware may vary from image shown, as new enhanced items are made available)

-

YouTube Video
of Module Operating

Optional Colors Available
for Brackets / Components

With this system you get a complete R/C Servo, Pull Pull module bracket assembly connected to servo, steel multi strand pull cable and cable sleeve to connect up a mechanical motion linkage unit for use with Animatronics, props or device when motion is needed in a small space or a mechanical design where a push rod may not work well.
This pull-pull module can be mounted with the cable attached to the mechanicals at a different location, providing plus and minus pulling movements.

Module Includes:
3D Printed PLA- Plastic Servo mounting bracket, support and hardware
Servo - Metal Gears, Metal Output shaft and cable wheel with 3D printed plastic cable guide metal hub
Multi-Strand , Coated Cable-3 feet (Can be cut to any length)
Cable Slide Sleeve, Plastic-Nylon 3-Feet (Can be cut to any length)
4 Cable sleeve anchor hardware
4 Cable sleeve guide hardware

2 modules are available (Flat mount, or Rod mount servo mech)


(Servo Control Board, Power supply NOT included)

Steel multi strand pull cable and cable sleeve to connect up a mechanical motion linkage unit for use with Animatronics, props or device

User Guide

With this system you get a complete R/C Servo, Push Pull module bracket assembly connected to servo, ball joints, pull cable connect with a mechanical motion linkage unit for use with Animatronics, props or device when linear push pull motion is needed.

Module Includes:
3D Printed PLA- Plastic Servo mounting bracket, support and hardware
Servo assembly
Push Rod and 4-40 size ball joints
User Guide

2 modules are available (Flat mount, or Rod mount servo mech)

(Servo Control Board, Power supply NOT included)

Steel Push Rod to connect up a mechanical motion linkage unit for use with Animatronics, props or device
(4 each by 12 inch full length threaded rods included per package)

Fit into- Ball Ends and Socket Joints (4-40) / (2-56)

Size (4-40) 12" - All Threaded

Size (2-56) 12" - All Threaded

User Guide

Starter kit to create an animatronic talking Creepy Head.
Kit Includes AutoTalk, Servo, Mechanical linkage kit, Autotalk programming and application guide.
Low density poly-urethane foam Head

Kit requires an audio source to AutoTalk control board to make mouth move automatically, not included

NOTE: Precision 3D Printed PLA- Plastic Servo mounting bracket, support and hardware now included in kit. "Very Easy to Build Kit"
...

 "Talking Gabby" Prop" Mouth movements sync to sound tracks
AutoTalk Control Board
Head Base Plate
R/C Servo, mounting hardware, brackets
Power Supply - 9 Vdc.

(Audio source for AutoTalk, or microphone Not Included)

..........

....................

With this kit you get a heavy duty servo and manual servo controller

Kit includes:
Manual Servo Controller - Wizard -12 Board
Slide Potentiometer Board
Heavy Duty Servo Arms.
Dual Ball Joint Link (2-56 size).
Universal Servo Mount.
Heavy Duty Standard Servo
9 Vdc Power Supply - Wall adapter

( Note: Hardware may vary from image shown, as new items are made available. Precision 3D Printed PLA- Plastic Servo mounting bracket, support and metal hardware now included)
Mask, Character not included.

(J-connector on servo wire)

With this eye movement kit you can build a basic mechanical eye module that will move the eyes left and right using the attached micro R/C servo.

By connecting the R/C servo to any of the optional control board you can create a fully programmable eye module with automated control and playback or to the Wizard-12 controller if you want to manual control the eye movements left and right.

Newly Enhanced Version
Kit includes:
Precision 3D Printed PLA- Plastic Servo mounting bracket, support and metal hardware
2 - 24mm 1/2 ball realistic human eyes (0.946 inches)
Pico R/C Servo (GWS)
Precision 3D Printed PLA- Plastic Eye Movement brackets with metal ball joint and socket mounting hardware
Metal Servo linkage hardware rods / parts
Mounting Tabs for easier attachment to under-skull structures.
Simplified and easy assembly
Instructions / application overview

The eye module is based on real Human Scale
Eye center to center = 2-1/2" (center iris to center iris)
Eye ball size = 24mm
(Plastic 1/2 Ball with realistic black iris and surrounding coloring)
NOTE: Eye Color intensity (color dark/light brown) may vary from kit to kit.
Precision 3D Printed PLA brackets

Servo Control Board - NOT Included. If you want to control eyes, select optional control boards and purchase needed board.

Recommended Tools needed for kit assembly
(Not included in kit)
Screwdriver, Needle Nose Pliers
Drill and drill bit (3/32)
Super Glue- Thick or Gap Filling type
Sandpaper, X-Acto knife

Servo Control Board - NOT Included. If you want to control eye, select optional control boards and purchase needed board.

 Pro Mechanical Eye -1A
Servo WIDE

Pro Mechanical Eye -1B
Servo LONG

Servo Control Board - NOT Included

YouTube Videos
of Eye Module Operating

Precision Mechanical eye module that will move the eyes Left and Right using the attached R/C servo.

The eye module is based on real Human Scale
Eye center to center = 2-1/2" (center iris to center iris)
Eye ball size = 24mm
(Plastic 1/2 Ball with realistic black iris and surrounding coloring)
NOTE: Eye Color intensity (color dark/light brown) may vary from kit to kit. Plastic eyes will need to be glued onto eye movement posts

Includes:
Heavy Duty Standard R/C Servo with metal hub wheel
Precision 3D Printed PLA- Plastic Servo mounting bracket, support and metal hardware
Eye movement bracket / servo hub with metal mounting hardware
2 - 24mm 1/2 ball realistic human eyes (0.946 inches)
Metal Servo linkage hardware / parts
Instructions / application overview

Two Versions Available
Pro Mechanical Eye -1A - ( L/ R Movement Servo WIDE)
Pro Mechanical Eye -1B - (L/ R Movement Servo LONG)

Servo Control Board - NOT Included. If you want to control eye, select optional control boards and purchase needed board.
Eyes not glued onto movement posts, will require user to glue on eyes

By connecting the R/C servo to any of the optional control board you can create a fully programmable eye module with automated control and playback or to the Wizard-12 controller if you want to manual control the eye movements left and right.

Servo Control Board - NOT Included

YouTube Videos
of Eye Module Operating

Eyes not glued onto movement posts,
will require user to glue on eyes

Plastic eyes

Optional Colors Available
for Brackets / Components

Unique Precision mechanical eye module that will move the eyes Left, Right, Up and Down using just two attached standard R/C servos.

The eye module is based on real Human Scale
Eye center to center = 2-1/2" (center iris to center iris)
Eye ball size = 24mm
(Plastic 1/2 Ball with realistic black iris and surrounding coloring)
NOTE: Eye Color intensity (color dark/light brown) may vary from kit to kit. Plastic eyes will need to be glued onto eye movement posts

Includes:
Precision 3D Printed PLA- Plastic Servo mounting bracket, support and metal hardware
Two Heavy Duty Servos with metal hub wheels and metal mounting hardware
2 - 24mm 1/2 ball realistic human eyes (0.946 inches)
Metal Servo linkage hardware / parts
Instructions / application overview

Servo Control Board - NOT Included. If you want to control eye, select optional control board.
Eyes not glued onto movement posts, will require user to glue on eyes

By connecting the R/C servo to any of the optional control board you can create a fully programmable eye module with automated control and playback or to 2 Wizard-12 controllers if you want to manual control the eye movements left and right, and up and down.

Servo Control Board - NOT Included

YouTube Videos
of Eye Module Operating

Eyes not glued onto movement posts,
will require user to glue on eyes

Plastic eyes

Optional Colors Available
for Brackets / Components

Complete module with a mechanical eye module that will move the eyes Left, Right, Up and Down and moving eye lids using the attached heavy duty standard R/C servos and hardware.

The eye module is based on real Human Scale
Eye center to center = 2-1/2" (center iris to center iris)
Eye ball size = 24mm
(Plastic 1/2 Ball with realistic black iris and surrounding coloring)
NOTE: Eye Color intensity (color dark/light brown) may vary from kit to kit. Plastic eyes will need to be glued onto eye movement posts

Includes:
Standard R/C Servos with metal hub wheels.
Precision 3D Printed PLA- Plastic Servo mounting bracket, support and hardware
Eye movement bracket with metal mounting hardware
2 - 24mm 1/2 ball realistic human eyes
Metal Servo linkage hardware / parts
Instructions / application overview

Servo Control Board - NOT Included. If you want to control eye, select optional control board.
Eyes not glued onto movement posts, will require user to glue on eyes

By connecting the R/C servo to any of the optional control board you can create a fully programmable eye module with automated control and playback .

Servo Control Board - NOT Included

YouTube Videos
of Eye Module Operating


Plastic eyes

Eyes not glued onto movement posts,
will require user to glue on eyes

Optional Colors Available
for Brackets / Components

Complete module with a mechanical eyes Left, Right, Up and Down, Eye Lid Blink , and eye brow movements using the attached standard R/C servos.

The eye module is based on real Human Scale
Eye center to center = 2-1/2" (center iris to center iris)
Eye ball size = 24mm
(Plastic 1/2 Ball with realistic black iris and surrounding coloring)
NOTE: Eye Color intensity (color dark/light brown) may vary from kit to kit. Plastic eyes will need to be glued onto eye movement posts

Includes:
Standard, Mini R/C Servos
Precision 3D Printed PLA- Plastic Servo mounting bracket, support and hardware
Eye movement bracket with mounting hardware
2 - 24mm 1/2 ball realistic human eyes
Metal Servo linkage hardware / parts
Instructions / application overview

Servo Control Board - NOT Included. If you want to control eye, select optional control boards and purchase needed board.
Eyes not glued onto movement posts, will require user to glue on eyes

By connecting the R/C servo to any of the optional control board you can create a fully programmable eye module with automated control and playback .

This kit is similar to the Mechanical Eye Kit- A. With this complete kit you can build a Cyclops mechanical eye module that will move a single eyeball left and right using the included pico R/C servo.

By connecting the R/C servo to any of the optional control board you can create a fully programmable single eye module.

Eye ball size = 24mm
(Plastic 1/2 Ball with realistic black iris and surrounding coloring)
NOTE: Eye Color intensity (color dark/light brown) may vary from kit to kit.

Kit includes:
R/C Servo
Servo mounting bracket, support and hardware
Cast Urethane Resin Servo mounting bracket, support and hardware
Eye movement bracket with mounting hardware
1 - 24mm 1/2 ball realistic human eyes (0.946 inches)
Servo linkage hardware / parts
Assembly guide / application overview

Servo Control Board - NOT Included. If you want to control eye, select optional control boards and purchase needed board.

Material: Smooth Cast Urethane Resin - 70 D Hardness

Servo Control Board - NOT Included

YouTube Videos
of Eye Module Operating

Plastic eyes

Eyes not glued onto movement posts,
will require user to glue on eyes

Optional Colors Available
for Brackets / Components

Cyclops mechanical eye module that will move a single eyeball left and right, up and down using the attached R/C servo.

By connecting the R/C servo to any of the optional control board you can create a fully programmable single eye module.

Eye ball size = 24mm
(Plastic 1/2 Ball with realistic black iris and surrounding coloring)
NOTE: Eye Color intensity (color dark/light brown) may vary from kit to kit. Plastic eye will need to be glued onto eye movement post

Includes:
R/C Servo
Precision 3D Printed PLA- Plastic Servo mounting bracket, support and hardware, Servo mounting bracket, support and hardware
Eye movement bracket with mounting hardware
1 - 24mm 1/2 ball realistic human eye (0.946 inches)
Metal Servo linkage hardware / parts
Assembly guide / application overview

Servo Control Board - NOT Included. If you want to control eye, select optional control boards and purchase needed board.
Eye not glued onto movement post, will require user to glue on eye

Finished Mouth Prop View - A

New Enhanced Version

Finished Mouth Prop View - B
New Enhanced Version

NOTE: Mouth Kit comes as all WHITE plastic parts,
but can easily be custom painted, modified.

Servo Control Board - NOT Included

With this complete kit you can build a mechanical mouth module that will open and closed using the included Mini R/C servo.

By connecting the R/C servo to any of the optional control board you can create a fully programmable mouth module with automated control and playback or to the AutoTalk controller if you want to convert sound directly to servo motion control.

Material: Smooth Cast Urethane Resin - 70 D Hardness

Kit includes:
Micro R/C Servo
Mouth mounting bracket, support and hardware
Cast Urethane Resin Mouth movement bracket with mounting hardware
Cast Urethane Resin Realistic mouth with teeth and free movement animation tongue
Servo linkage hardware / parts
Assembly guide / application overview

NOTE: Mouth Kit comes as all WHITE plastic parts, can be painted with plastic paint, or Croma Key green or blue paint for video production.
Servos come black in color.
Material: Smooth Cast Urethane Resin - 70 D Hardness

Servo Control Board - NOT Included. If you want to control mouth, select optional control boards and purchase needed board.

....... Example of Finished Mouth

YouTube Video Mouth Opeating
. ...........New Enhanced Version

Mechanical mouth module that will open and closed using the attached R/C servo.

By connecting the R/C servo to any of the optional control board you can create a fully programmable mouth module with automated control and playback or to the AutoTalk controller if you want to convert sound directly to servo motion control.

Includes:
R/C Servo
Precision 3D Printed PLA- Plastic Servo mounting bracket, support and metal hardware Mouth mounting bracket, support and hardware
Mouth movement bracket with mounting hardware
Realistic mouth with teeth and free movement animation tongue
Metal Servo linkage hardware / parts
Assembly guide / application overview

NOTE: Mouth comes as all WHITE PLA 3D Printed plastic parts, can be painted with plastic paint, Servos come black in color.

Servo Control Board - NOT Included. If you want to control mouth, select optional control boards and purchase needed board.

Click on images for closeup views

NOTE: Mouth Kit comes as all WHITE plastic parts,
but can easily be custom painted, modified.

Servo Control Board - NOT Included

With this kit you can build a mechanical animal mouth module that will open and closed using the attached micro R/C servo.

By connecting the R/C servo to any of the optional control board you can create a fully programmable mouth module with automated control and playback or to the AutoTalk controller if you want to convert sound directly to servo motion control.

Kit includes:
Micro R/C Servo
Precision 3D Printed PLA- Plastic Servo mounting bracket, support and metal hardware Mouth mounting bracket, support and hardware
Mouth movement bracket with mounting hardware
Realistic animal mouth with teeth and free movement plastic animation tongue
Servo linkage hardware / parts
Assembly guide / application overview

NOTE: Mouth Kit comes as all WHITE plastic parts, can be painted with plastic paint, or Croma Key green or blue paint for video production.
Servos come black in color.

Servo Control Board - NOT Included. If you want to control mouth, select optional control boards and purchase needed board.

Complete mechanical hand module that will move using the attached R/C servo Pull Pull Cable Mechanism and Servo controller board

Includes:
R/C Servos
Pull Pull- Servo Mechanism
Precision 3D Printed Plastic Servo Control Module support and metal hardware, Servo mounting bracket, support and metal rdware
Servo Controller Board
Human Scale - Cyborg style available
Guide / application overvie
Power Supplies

Mouth Open / Close with Left / Right turning mechaism attached on aluminum rod support

Includes:
R/C Servos (Mouth / Turning)
Pull Push - Servo Mechanism for mouth control
Servo Mechanism for left and right Rod movement
Precision 3D Printed PLA- Plastic Servo Control Module support and Metal hardware, Servo mounting bracket, support and hardware
Metal Servo Push Pull hub.

Guide / application overview

Optional eye assembly available to attach onto rod

(Servo Control Board, Power supply, Puppet NOT included)

Mouth : Open / Close
Head Rotate (Pan): Left / Right
Head Tilt: Up / Down
Eye Module Left Right
(Optional; Eye Module L/R-U/D Available)

Includes:
R/C Servos (Mouth / L/R Turning)
Pull Push - Servo Mechanism for mouth control
Servo Mechanism for left and right Rod movement
Precision 3D Printed PLA- Plastic Servo Control Module support and Metal hardware, Servo mounting bracket, support and hardware
Metal Servo Push Pull hub.

Guide / application overview

Optional eye assembly available to attach onto rod

(Servo Control Board, Power supply, Puppet NOT included)

YouTube Videos
of Module Operating

Optional Colors Available
for Brackets / Components

Mechanical module that attaches to standard silly string can and allows user to control string shooting action by R/C servo mechaism attached and optional Servo Control boards or RF Wireless Controllers.

Includes:
R/C Servos
Pull Pull - Servo Mechanism for can spray control
Precision 3D Printed PLA- Plastic Servo Control Module support and hardware, Servo mounting bracket, support and hardware

Guide / application overview

(Servo Control Board, Power supply, Silly String Can, RF Wireless controller NOT included)

Optional Colors Available
for Brackets / Components

Mechanical module that attaches to standard "Fog in a Can" and allows user to control fog/Mist spray action by R/C servo mechaism attached and optional Servo Control boards or RF Wireless Controllers.

Includes:
R/C Servo
Pull Pull - Servo Mechanism for can spray control
Precision 3D Printed PLA- Plastic Servo Control Module support and hardware, Servo mounting bracket, support and hardware
Horizontal and Vertical Mounting

Guide / application overview

(Servo Control Board, Power supply, "Fog in a Can", RF Wireless controller NOT included)

YouTube Videos
of Module Operating

Optional Colors Available
for Brackets / Components

Mechanical module that bangs, "Thumps" againt floor, wall, box sides, etc. with thumping action controlled by optional Servo Control boards or RF Wireless Controllers.
Module can be mounted vertical, horizontal, or angled
Adjustable End adapter block , with anchor holes for add-on strike block, metal plate, etc.

Includes:
R/C Servo
Thumper - Servo Mechanism (Adjustable length and end adapter)
Precision 3D Printed PLA- Plastic Servo Control Module support and hardware, Servo mounting bracket, support and hardware

Guide / application overview

(Servo Control Board, Power supply, RF Wireless controller NOT included)

Mechanical module that connects to Air Horn unit and is controlled by optional Servo Control boards or RF Wireless Controllers.
The Air Horn is very loud, and can be re-charged by air supply sourcs (Hand pump, Air cylinder, mobile air tank, compressor etc.)

Air Horn -Emits 115 dB Sound (Can be heard -1/2 mile away)
Air Horn Size: Aprox - 8" long x 5-1/2" wide-1 x 5-1/2" wide-2

Can product 50 half second blasts on just 80 psi air charge
Lightweight module

Includes:
R/C Servo
Air Horn unit- Servo Mechanism
Precision 3D Printed PLA- Plastic Servo Control Module support and Metal hardware, Servo mounting bracket, support and hardware
Hand Air Pump (Manual air refill)

Guide / application overview

(Servo Control Board, Power supply, RF Wireless controller NOT included)

YouTube Videos
of Module Operating

Optional Colors Available
for Brackets / Components

Mechanical module that connects to rechargable Spray Air Can unit and is controlled by optional Servo Control boards or RF Wireless Controllers.
The spray can be re-charged by air supply sourcs (Hand pump, Air cylinder, mobile air tank, compressor etc.) and can spray liquids, smells, or air stream.

Includes:
Air Can Sprayer with refill valve and spray valve
Pecision 3D Printed PLA mounting and holding bracket
R/C Servo
Air Can Spray unit- Servo Mechanism
Precision 3D Printed PLA- Plastic Servo Control Module support and Metal hardware, Servo mounting bracket, support and hardware

Guide / application overview

(Servo Control Board, Power supply, RF Wireless controller NOT included)

Mechanical Wing modules (Wing Out, Wing Foward, Backwards)

Precision 3D Printed PLA- Plastic Servo Control Module support and Metal hardware, Servo mounting bracket, support and hardware

R/C Servos - Pro Version Pull - Pull Servo Mechanism

(Servo Control Board, Power supply, RF Wireless controller NOT included)

Pro Mechanical Wing -A
Mechanism (Flat Surface Mounting)

Pro Mechanical Wing -B
Mechanism (Rod Mounting)

(Optional; Wings attached, not included)

Mechanical modules
Wings attached to movement arms and move back and forth under servo control
Precision 3D Printed PLA- Plastic Servo Control Module support and Metal hardware, Servo mounting bracket, support and hardware

(Optional; Wings attached , not included)

(Servo Control Board, Power supply, Optional Wings, RF Wireless controller NOT included)

Pro Mechanical Wing -A
Mechanism (Flat Surface Mounting)

Pro Mechanical Wing -2
Mechanism (Rod Mounting)

Mechanical Tail modules

Precision 3D Printed PLA- Plastic Servo Control Module support and Metal hardware, Servo mounting bracket, support and hardware
Pull-Pull cable Servo modules

Pro Mechanical Moving Tail Module - A10"

Pro Mechanical Moving Tail Module - B 6"

(Servo Control Board, Power supply, RF Wireless controller NOT included)

Mechanical Motion module for UAV Ground Tracking System

Precision 3D Printed PLA- Plastic Servo Control Module support and Metal hardware, Servo mounting bracket, support and hardware


(Antenna, UAV Mobile Control System, Servo Control Board, Power supply, RF Wireless controller NOT included)

Examples of Animatronic Head Kit

Starter kit to create an animatronic (moving Mouth, Eyes- L/R, Head L/R Motion ) basic plastic head kit

Kit includes:

Quality Plastic Sculpted Head pieces (Front, Back) and Plastic moving Mouth unit

Electronics, Mechanical modules not included, but available as add-on.


Head Kit comes as all WHITE plastic parts, can be painted with plastic paint, or Croma Key green or blue paint for video production.

These servo brackets will allow you to easily mount any standard size servo and then connect the bracket to a 2" PVC pipe in various angles needed.

Kit includes:
Servo Mounting Bracket and Support Block
Mounting hardware
Servo Linkage Hardware
Instructions / Application Overview

Brackets Kits comes as all WHITE plastic parts, can be painted with plastic paint, or Croma Key green or blue paint for video production.
Material: Smooth Cast Urethane Resin - 70 D Hardness

Incredible realistic looking acrylic half eyes in 24 mm sizes.

Each eye is a half sphere

2 Eyes per set.

NOTE: Eye Color intensity (color dark/light brown) may vary

Incredible realistic looking hollow acrylic eyes in 24-26 mm size.

Each eye has a plastic hollow extension (Stem) behind the hollow eye for connections of ball joints, push rods or to glue to.

2 Eyes per set.

. . Green (GR)
. . Brown (BR)
. . Blue (BL)
. . Gray (G)

NOTE: Eye Color Intensity (color dark / light shades) shown may vary due to manufacturing process. (All eye sets are matched together for same color variations)

Clear Rubber Eyes with Veins
( 24mm )


White Plastic Eyes with Veins
( 24mm )

Documentation / User Manual

Complete DMX controller kit with all hardware, cables, software and components to assist in the development of an animatronic setup controlled by DMX.

This kit contains all the basic components to setup a full working DMX controlled environment for use in animatronics.

Contact Blue Point Engineering for more details.

We can custom design just about any project that you may be interested in.
