LED EYES can be adjusted to fade up and down in brightness or adjusted to strobe ON and OFF. Adjustable fade / strobe rate from Near OFF to near strobe ON like.

Small Controller Box :
2" L x 1-1/4" W x 3/4" H
18" wire lead from box to LED's
24mm Plastic Eyeball with LED inside
On board adjustable fade/ strobe rate knob
Choice of LED colors
( Red, Green, Yellow )
Quality engineered device ( Pro Level )
9Vdc battery powered.
( Battery not included )

Can be adjusted to fade up and down in brightness or adjusted to strobe ON and OFF. Adjustable fade / strobe rate from near OFF to near strobe ON like..

Small Controller Box - 2" L x 1-1/4" W x 3/4" H
18" wire lead from box to LED's
Choice of LED color ( Red, Green, Yellow )

Quality engineered device ( Pro Level )
9Vdc battery powered. ( Battery not included )

5mm - RGB LED on quick wire adapter with current limiting resistors on board.
Adapter is set up for 9-12 Vdc Input
(Red- Resistor 220 Ohm, Green/Blue- Resistor 330 Ohm at 9-12 VDC supply

RGB LED ( 4 lead wires from LED )

Common Anode (Positive) configuration
Emits: Red-Green-Blue Light - Defused Lens for even coloration

Wavelength:
RED = 5624nm
GREEN = 525nm
BLUE = 1470nm

5mm - Bi-Color LED (Red / Green) on quick wire adapter with current limiting resistors on board.
Adapter is set up for 9-12 Vdc Input
(Red- Resistor 220 Ohm, Green- Resistor 330 Ohm at 9-12 VDC supply

Bi-LED ( 3 lead wires from LED )

Common Cathode (Negative) configuration
Emits: Green-Red Light - Defused Lens for even coloration
Wavelength:
RED = 5624nm
GREEN = 525nm

10mm clear / diffused lens RGB LED in common-anode configuration.

Large 10-mm LEDs with four leads. Common Anode (+),and Red(-), Green(-), Blue(-) Leads
Big and bright design.
Clear-lens projects high brightness for visibility at a distance.
Diffused-lens excellent color blending

Forward voltage = 2.5 Vdc.
Forward current = 30 mA average

Unique LED with built-in integrated circuit to create a candle-like random-flickering effect. The yellow LED element is a super bright device in a 5mm clear-lens package.
(LED for use in electronic candles, Halloween, any place a flame effect is needed)

Flickering yellow LED is a super bright 2000 mCd device
Forward voltage = 2.1 Vdc.
Forward current = 25-30 mA average
20 Degree View Angle
Water Clear, Yellow (5mm)

NOTE: Because of the integrated flicker circuit, the LED element is offset from center in the LED package, so the projected spot of light comes out at a slight angle and not straight upward.

Unique LED with built-in integrated circuit to create a candle-like random-flickering effect. The white LED element is a super bright device, in a 10 mm diffused, milky-white translucent lens package.

Forward voltage = 2.7 V dc
Forward current = 25-30 mA average
50 Degree View Angle
Diffused, milky-white translucent (10mm)

 Unique 5mm clear lens RGB LED flashes with a series of quick flashes; red, green, blue, red+green, green+blue, blue+red, and then all three at once. It repeats this fast cycle 2 times. Next, the red fades on, stays on for about 2 seconds, then fades out. Same with green, then blue, then red+green, green+blue, blue+red, and then all three. It does this slow fade for two entire cycles; then everything begins again.
RGB flash circuit built-into LED base
RGB LED - 3.1 vdc @ 25 -30 mA - ( 2 lead wires from LED )

LED Effects Unit Document
Effects Video

-Micro LED ( Green, Yellow, Red Colors )

-- Resistor included

NOTE: These LED's are extremely delicate and should be handled with great care.
Extra caution should be used to make sure that the operating voltage and current do not exceed the specifications and ratings required.

  -Small Mini LED's with built-in blinking circuit.

LED Power Driver Board
8- Channels
9-12 VDC input, with regulated 5 VDC @ 1 amp output
330 Ohm built in resistor network
No resistors need to be added to attached standard 5mm or 10mm 1-3 VDC @ 30 mA LED's

Power Switch, On and Off
Quick Power Jack or Power Wire Terminal Block
Micro Wire Terminal Blocks for LED's ( + and - )

( Power supply and LED's not included )

Luxeon LED modules - 350 mA - 80 Lumens. 3.5 to 4.5 VDC

Note Luxeon LED require a heat sink for proper performance and longevity. The LED.must be attached to a Heatsink.
Luxeon LED's also require a steady power driver to operate the LED module at peak performance.

What is a Luxeon LED

Luxeon Power LED's offer significant advantages over standard Super-bright LEDS. With up to 120 Lumens of Light output, they are very bright having the highest flux in the world. The standard Luxeon White LED will produce 20 lumens per watt which is 5 to 20 time brighter then standard LED's.

A standard Luxeon LED will last up to 10 years or 50,000 hours with correct voltage and current supplied to the LED module.

Luxeon LEDs are small, directional pinpoints of light which result in highly controllable optical systems with no wasted light. No moving parts, nothing to break, shatter or leak. No UV or Heat is contained in the Light output, but there is heat generated on the back side of the Luxeon LED which will need a heat sink attached for proper performance and longevity of the LED.

All Luxeon LEDs are DC voltage operation devices

These universal 19 Inch Flex-LED Surface Mounted Light Strips are excellent for use in projects requiring lighting or for use when special effect lighting is need and connected to an FX controller.

The LED strips are very flexible and can be wrapped or attached to almost any surface and shape. Each strip comes with an Adhesive back so they can mount just about anywhere.

The standard colors have an LED spaced 5/8" apart, 30 LED's Per Strip. Strips are 1/4" Wide x 19" Long, or when cut to the smaller length ( 3 LED's ) is 2" long x 1/4" wide.

Strips are easily cut to different sizes with cut markings shown on the tape so that you always get the proper LED's to resistor ratio needed.
Smallest size that can be cut is A 3 LED strip. When properly cut each strip also contains a solder pad for the connection of the positive and negative power wires.

Each strip operates from 12vdc @170mA per 19" length.

Note: The minimum bending radius is 2 cm. The strip may be bent over a smaller radius of the circuit board containing no electronic components and such bends should be made once and fixed in position to avoid cyclic fatigue.

Lumen Output :
White = 600 at 12vdc @170mA
Blue = 300 at 12vdc @170mA
Green = 500 at 12vdc @170mA
Red = 500 at 12vdc @170mA
Yellow = 450 at 12vdc @170mA

( 12 VDC Power Supply , power connection wires and controller not included. Stripes do not have power wires connected, some soldering required to attach wires or quick connectors can be used )

NOTE: LED Strips do not come with Power Wires connected.

Image Coming Soon

-
LED Strips do not come with Wires
connected, Image shown, illustrates typical
connection that can be easily done.
Optional Quick Connectors available.


NOTE:

LED RGB Setup is
Common Anode Configuration

LED Strips do not come
with Wires connected.

These universal 19 Inch Flex-RGB LED Surface Mounted Light Strips are excellent for use in projects requiring lighting or for use when special effect lighting is need and connected to an FX controller.

The LED strips are very flexible and can be wrapped or attached to almost any surface and shape. Each strip comes with an Adhesive back so they can mount just about anywhere.

The RGB LED's are spaced 5/8" apart, 30 LED's Per Strip. Strips are 1/4" Wide x 19" Long, or when cut to the smaller length ( 3 LED's ) is 2" long x 1/4" wide.

Strips are easily cut to different sizes with cut markings shown on the tape so that you always get the proper LED's to resistor ratio needed.
Smallest size that can be cut is A 3 LED strip. When properly cut each strip also contains a solder pad for the connection of the positive and negative power wires.

Each strip operates from 12vdc @170mA per 19" length.
LED RGB Setup is Common Anode configuration

Note: The minimum bending radius is 2 cm. The strip may be bent over a smaller radius of the circuit board containing no electronic components and such bends should be made once and fixed in position to avoid cyclic fatigue.

Lumen Output :
Red = 500 at 12vdc @170mA
Blue = 300 at 12vdc @170mA
Green = 500 at 12vdc @170mA

( 12 VDC Power Supply , power connection wires and controller not included. Stripes do not have power wires connected, some soldering required to attach wire, or quick connectors can be used )

NOTE: LED Strips do not come with Wires connected.

Click on image for closeup view

Click for example LED bar setup

LED Light Bar - 3-1/2" L x 5/8" W x 5/8"H

LED Light Bar - 3-1/2" L x 5/8" W x 5/8"H





( 12 VDC Power Supply and Controller not included. )

If your unsure what to purchase but wish to start learning about the Luxeon LED modules, then try our Luxeon LED Starter Kit.

The kit comes with your choice of:
1 - Watt Luxeon Star LED module, you pick color.
1 - Small Heatsink with self-stick backing.
1 - Micro-2004 Driver and connection cable.
1 -"AA" Battery Holder, and Instructions.

Luxeon LED's available in
Red, Green, Blue, White Modules

.....................Kit Instructions

( "AA" Battery not included )

Made from thin, laminated plastic sheets, this E.L lamp (Electroluminescent ) gives off a neon / fluorescent glow, without generating any heat or hot spots. Just print your computer-created or hand-drawn full-color artwork on transparent film or decal paper then apply to the E.L. lamp and trim to shape, plug in the miniature power inverter and hit the switch. The effect is awesome!
Add drama to your models with these Electroluminescent lamps. Make your own lighted building signs, auto and airplane instrument panels, theater marquis, science-fiction special effects, etc.

Includes one 1-3/4 inches W x 3-3/4 inches L x .010 inch thick lamp, six colored overlays, one power inverter with switch, and 12 page instruction manual.
( requires two AAA batteries not included in kit )

Made from thin, laminated plastic sheets, this E.L lamp gives off a neon / fluorescent glow, without generating any heat. Just apply your full-color artwork transparent film or decal to the E.L.lamp, then using a special power inverter to sequentially light up to six segments of the E.L. lamp with 32 different user-selectable chase patterns. The effect is very awesome!

Includes one 1-3/4 inches W x 3-3/4 inches L x .010 inch thick lamp, six colored overlays, one sequentially power inverter with 32 different user-selectable chase patterns and instruction manual.
( requires two AAA batteries not included in kit )

LED Strobe has 8 - high output 5mm LED's on board, that strobe ON and OFF
You adjust the flash rate of LED ON/ OFF with the on-board potentiometer.

Powered by 9 Vdc Battery
LED colors = ( Red, Green, Yellow, White, Blue )

Board Size Approx: 3-3/4" L x 1/2" W x 1/2" H
( 9 Vdc battery not included )

 The lighting board produces a simulated flame / fire lighting effect and is the most accurate lighting package of its kind. Flame with out fire, this effect is designed for model trains, general dioramas, architectural models, doll houses and where ever you would need the flame look.

1 - Yellow LED's
2 - Red LED

Adjustable flame flicker rate
Power On and Off switch
PIC microprcessor on board - generated effects
9Vdc Battery Snap connector
small board

Board Size Approx: 1-5/8" L x 1" W x 5/8" H

( 9V Battery not included )

Lighting board produces a simulated Fire Fly lighting effect and is the most accurate lighting package of its kind.

Fiberoptic cable can be connected to each LED to produce multiple Fire Flies

Onboard power switch, Fire Fly adjustments
PIC microprcessor on board - generated effects
8 Channels of LED's

Board Size Approx: 3-1/4" L x 2=1/4" W x 5/8" H

( 9V Battery not included )

Unique board will flash LED's twice in one pulse (Heart Beat Like Effect)
Adjustable LED Beat speed

Board Size Approx:

( 9V Battery not included )

The Chaser-10 effects unit has 10 colored LED's that light from 1-10.
You can vary the speed with on board potentiometer control.

Comes with 2-White, 2-Blue, 2-Green, 2-Yellow, and 2-Red LED's
on circuit board.

9Vdc battery powered. ( Battery not included )

Twelve (12) high output LED's attached to wire leads with ON and OFF Power Switch and 9 Volt battery holder connected to electronic control circuit board.

Excellent for special effects in model building , costume designs or custom projects needing multiple LED lights.

Small controller board.
Approx.. 2-3/4" L x 2" W x1" H
12" wire lead from circuit board to LED's

Choice of LED colors:
( Red, Green, Yellow, Blue, White and RGB LED

Four (4) high output LED's attached to wire leads with ON and OFF Power Switch and 9 Volt battery holder connected to electronic control circuit board.

Excellent for special effects in model building , costume designs or custom projects needing several LED lights.

Small controller board.
Approx.. 2-3/4" L x 2" W x1" H
6" wire lead from circuit board to LED's

Choice of LED colors:
( Red, Green, Yellow, Blue, White and RGB LED

"Marquee" LED unit will flash 1 to 10 high output LED's in a Count to and Repeat Mode, you pick the number you wish it to count to and recycle to by using on-board jumpers. Adjustable LED speed rate. Perfect for models or costumes, especially when connected with fiber optics.

KIT Module - Includes all parts, instruction, you assemble - soldering and electronics knowledge required for kit assemble.

PC Board is 1-1/4" x 1-1/2"

( 9 Vdc battery not included )

Marquee Kit Manual

Optional Fiberoptic Cable for LED's

Lighting board operates a set of LED's in pairs turning on and off, fading effects. Great for sticking around in bushes for Halloween or in animatronic projects to simulate animal eye sets. (Bats, Monsters, Animals, Multiple Cyclops)

LED are not attached to board, and must be connected by user to wire and to the controller board. KIT Module - Includes all parts, instruction, you assemble - soldering and electronics knowledge required for kit assemble

On board power switch, LED Effects adjustments
PIC microprcessor on board - generated effects
4 Sets of 2 LED's each to form eye pairs

Board Size: 3-1/4" L x 2=1/4" W x 5/8" H

( 9V Battery not included .Connection wire for LED's not included)

click on images for closeup views

Main CPU Board Size:
2-3/4" Long x 2-1/8" Wide x 1" High

LED (2) Board Size:
1-1/8" Long x 1/2" Wide x 3/8" High

Power Adapter Board Size:
1" Long x 7/8" Wide x 3/8" High

CDS Sensor Board Size:
7/8" Long x 1/2" Wide x 1-1/4" High

Power Supply
7-24 V DC @ 100 mAmp Power Supply ..

Board is pre-assembled and tested.

Application Example


Click on image for a setup view

This Microprocessor controlled board was designed to produce 15 different light effects via 2 Bi-Color LEDs. A shadow moving across a CDS cell will trigger the selected effect. Once triggered, the effect will last for a period of time determined by the Cycle Time Potentiometer which can be up to 30 seconds long.

The rate at which the effect occurs (i.e., flashing, fading) is determined by the Rate Potentiometer. Every time an effect is triggered, a 80 mS pulse occurs at the Synch Output terminal block. This can be used to trigger another board.

All connections to the board are through small daughter boards. The board requires a 7.5 to 24V DC, 100 mA power supply.

Mode 1: Two LED's will strobe RED when activated.
Mode 2: Two LED's will strobe GREEN when activated.
Mode 3: Two LED's will fade RED up and down.
Mode 4: Two LED's will fade GREEN up and down.
Mode 5: One LED will strobe GREEN and the other will strobe RED.
Mode 6: One LED will fade up and down GREEN and the other LED will fade up and down RED.
Mode 7: LEDs will alternate strobing RED
Mode 8: LEDs will alternate strobing GREEN.
Mode 9: LEDs will alternate strobing RED and then GREEN.
Mode 10: One LED will strobe RED while the other LED fades up and down GREEN.
Mode 11: LEDs will fade up RED and then stay on for one minute and then fade down.
Mode 12: Both LEDs will come on RED, stay on for the set Cycle Time, then flash 3 times, stay on for another Cycle Time and then go off.
Mode 13: Both LEDs will come on GREEN, stay on for the set Cycle Time, then flash 3 times, stay on for another Cycle Time and then go off.
Mode 14: LED's fade up RED, then fade to ORANGE, then to GREEN and then fades off.
Mode 15: One LED fades up RED, then fades to ORANGE, then to GREEN and then fades off while the other fades up GREEN, then fades to ORANGE, then to RED and then fades off.
Mode 16: In this mode, each time the board is triggered, it cycles through each of the 15 modes one at a time.



( Power Supply , Robot Head Prop, Connection Wires not included )

LED Strobe has 1 - 5mm LED's on board, that strobe ON and Off.
You adjust the flash rate with the on-board potentiometer.

Powered by 9 Vdc Battery

LED colors ( Red, Green, Yellow, White, Blue )

Board is 1" x 1" x .5"

( 9 Vdc battery not included )

LED Strobe has 2 - 5mm LED's on board, that strobe ON and Off.
You adjust the flash rate with the on-board potentiometer.


Powered by 9 Vdc Battery

Mix or Match LED colors
( Red, Green, Yellow, White, Blue )

Board is 1" x 1" x .5"

( 9 Vdc battery not included )

Effects Video

LED Strobe has 4 - high output 5mm LED's on board, that strobe ON and Off.
You adjust the flash rate with the on-board potentiometer.


Powered by 9 Vdc Battery

Mix or Match LED colors
( Red, Green, Yellow, White, Blue )

Board is 1-1/2" L x 3/4" W

( 9 Vdc battery not included )

LED Strobe has 8 - high output 5mm LED's on board, that strobe ON and Off.
You adjust the flash rate of LED On / Off with the on-board potentiometer.
Board has connection for remote On / Off Switch or can be jumpered for Power all ON
Powered by 9 Vdc Battery
Mix or Match LED colors
( Red, Green, Yellow, White, Blue )

Board size: 2-3/8" L x 3/4" W x 1-3/8" H
( 9 Vdc battery not included )

KIT Module - Includes all parts, instruction, you assemble - soldering and electronics knowledge required for kit assemble.

LED Fader - 2 will fade 2 LED's from low to high in light intensity in repeating cycle.

Adjustable fading rate potentiometer built-on board to change fading from low to high speeds.

Two 5mm LED's

Powered by 9 Vdc Battery

Mix or Match LED colors
( Red, Green, Yellow, White, Blue )

Board is 1" x 1" x .5"
( 9 Vdc battery not included )

LED Fader - 4 will fade 4 LED's from low to high in light intensity and alternate back and forth between LED sets in repeating cycles.
the first 2 LED's fade up as the other 2 LED's fade down.
Adjustable fading rate potentiometer built-on board to change fading speed.
Four 5mm LED's

Powered by 9 Vdc Battery
Mix or Match LED colors
( Red, Green, Yellow, White )

Board is 1" x 1" x .5"
( 9 Vdc battery not included )

High Output LED vertical Strobe board mounted on 9 Vdc battery holder. You adjust the flash rate with the on-board potentiometer.
Eight (8) high output 5mm LED's on board, that strobe ON and Off.
Unit has Power On / Off switch, Strobe adjustment potentiometer . LED's control circuit and 9Vdc battery holder attached to driver board.
Unit stands on end, with controls near base and LED's at top.

Powered by 9 Vdc Battery

Mix or Match LED colors in circular pattern
( Red, Green, Yellow, White, Blue )

Unit Size: 2-1/4" H x 1- 1/4" W x 1-1/4" D
8 - 5mm LED's in circular pattern

( 9 Vdc battery not included )

High Output LED vertical Fader board mounted on 9 Vdc battery holder. You adjust the fade rate up and down with the on-board potentiometer.
Two (2) high output 5mm LED's on board, that fade ON and Off.
Unit has Power On / Off switch, Fader adjustment potentiometer . LED's control circuit and 9Vdc battery holder attached to driver board.
Unit stands on end, with controls at top and LED's near base.

Powered by 9 Vdc Battery

LED colors
( Red, Green, Yellow, White, Blue )

Unit Size: 2-1/4" H x 1- 1/4" W x 1-1/4" D
2 - 5mm LED's

( 9 Vdc battery not included )

Cylon or Knight Rider LED circuit will flash 6 - 5mm size LEDs back and forth. You can adjust the rate with the on-board potentiometer.
Powered by one - 9v battery .

Perfect for models or costumes.

Board is 1-3/8" x 1-1/2"

( 9 Vdc battery not included )

Small LED Strobe board with remote LED's
You adjust the flash rate with the on-board potentiometer.
High output 5mm LED's on remote board, that strobe ON and Off.

Powered by 9 Vdc Battery

Mix or Match LED colors in circular pattern
( Red, Green, Yellow, White, Blue )

Control Board is 1-1/2" L x 5/8" W
LED Board is 1" L x 1" W with 8 - 5mm LED's
8" cable between Control board and LED Board.
Optional LED Strobe Boards are available, in Rectangular, and In-Line LED patterns.

( 9 Vdc battery not included )

Small Twin LED Strobe boards with remote LED's
You adjust the flash rate of each strobe board with the on-board potentiometers
.
High output 5mm LED's on remote LED board, that strobe ON and Off from near OFF to full all ON.

On-board Power Switch with Red LED power on indicator

Powered by 9 Vdc Battery

Mix or Match LED colors in circular pattern
( Red, Green, Yellow, White, Blue )

Control Board is 1-1/2" L x 1-1/8" W
LED Board is 1-1/8" L x 7/8" W with 8 - 5mm LED's
8" cables between Control board and LED Boards.

Optional LED Strobe Boards are available, in Rectangular, and In-Line LED patterns.

( 9 Vdc battery not included )
...

Two 5mm high output LED's that alternately blink Back and Forth, similar to a railroad crossing signal.
Powered by 9 Vdc Battery
LED's flash 1-2-1-2-1-2
Mix or Match LED colors
( Red, Green, Yellow, White, Blue )

Board is 1" x 1" x .5"

( 9 Vdc battery not included )

8 - Fader Module will fade 8 high output LED's from low to high in light intensity with repeating cycle.

Adjustable fade rate potentiometer built-on board to change fading from low to high speeds. On board On / Off Power switch and power supply terminal block.
Module can be used as 4 sets of animal eyes, example 4 bats hanging from a tree with special effect lighted eyes or 8 individual LED's.

Custom LED sizes can be ordered for this module. ( 5mm,, 3mm)

Module comes with Eight (8) - 5mm LED's, Controller PCB and components, Instruction guide.

KIT Module - Includes all parts, instruction, you assemble - soldering and electronics knowledge required for kit assemble

Powered by 9 Vdc Battery
(Battery and LED Wire not Included)
LED colors
( Red, Green, Yellow, White, Blue )

Board is 2-3/5" L x 5/8" W x 1/2"H
( 9 Vdc battery not included )

Modular Eye Effects System allow the option of controlling up to 12 Plus eye effect modules from one power controller. Fading or Strobe Eye modules can be combined together to create the unique look of multiple eyes in the bushes, on a dungeon wall, or prop effect of lighted eyes. Power modules can be chained together to form a lot of eyes.Wires connect to the Power Module and to each Eye Module allowing you to place modules at different locations and lengths away from the power supply. Each eye module has on-board electronics for specific effects and comes with 2 feet of connection wire. Additional wire lengths can be purchased from any electronics or hardware store for custom lengths as you need.

Strobe Eye Module
Round plastic eye set with LED mounted inside each eye, controlled by on board strobe electronics. Adjustable strobe rate from Near OFF to full fast ON flashing.

Glowing / Fading Eye Module
Round plastic eye set with LED mounted inside each eye, controlled by on board electronics. Adjustable fade rate from Near OFF to full ON fading up and down,

Power Module provides power to each of the 12 channels. Board has an On and Off switch with Power On LED status indicator. Wire Tie holes securely hold lead wires to each eye module. Quick wire terminal blocks, makes connections easy and fast. 9 Vdc power jack and multiple chain together wire terminal blocks built on board.
Note: One Power Module is needed for every 12 Eye Modules . One Module must be purchased.

Unit operates from a 9 Vdc power supply not included

Fiber-optics Controller Document

9 Vdc battery power source for use with Fiber optic endglow cables.

Controller components:
Endglow fiber holder connector.
Plastic box with internal LED light source.
Battery snap connector ( 9Vdc )
5 mm LED - color your choice

Your choice of LED:
(x)= Red, Blue, Green, Yellow, White
or RGB LED

( 9 Vdc battery not included )
( Endglow Fiber- cable not included NOTE )

Unique board combined with special holder will secure fiber optic cable to 3 LED's
Each module has 3 on-board LED's and resistors for quick setup.
Special Connector will clamp down on cable for a quick, easy and secure method for attaching LED's to fiberoptic cable.
Board has power connection for connecting remote activation by relays, switches or controller power board.
Wire terminal blocks for quick connection.

Holder and fiber-optic cable can be connected by power wire from controller located in different location, saving fiber cable needed and keeping LED light source close to fiber-optics output area.

Holder boards can be daisy - chained for multiple location setup.

Board requires 9-12 Vdc to operate LED's

Fiberoptic Connector / LED Driver Board Size:
3-3/4" L x 2-1/2" W x 1/2" H

( Power supply, LED controller board's not included )

Optical fibers attached to single 5mm LED source.
Light shines out end of fibers. Fibers can be cut to various length as needed, glued, wired, or taped to secure in projects. Optical Fibers are attached to LED through special metal LED and fiber holder.

This module is great for floral arrangements, centerpieces, holiday projects, posters, art projects and even model builders needing unique lighting effects.

Module operate on batteries, wall adapter
( any 9Vdc - 800mA power supply )

LED power wire - 12" Long - Black (-) / White (+)
20 - Optical Fibers -Approx: 21" Long

BLUE, RED, GREEN Colors available

Resistor included for 9 Vdc power supply

Instruction manual, application guide.

Light source: one - 5mm LED

LED and Fiber holder Size: 1- 3/8" L x 3/8 W

( power supply , batteries, projects not included )

Unique board will control 6-Strobe LED's, 6-Fading LEDs, and 8-Switched On and Off LED's by remote activation.
Board has input connection for remote activation by relays, switches or controller board.
Each Switch Bank will control one effects section
LED Wire terminal blocks for quick connection
Board requires 9 Vdc @2 Amp Power supply
500 mA per channel output

Driver Board Size:
3-3/4" L x 2-1/2" W x 1/2" H

( Power supply, LED's not included )

Unique board will control 6-Beacon LED's, 10-Chasing LEDs by remote activation.
Board has input connection for remote activation by relays, switches
or controller board.
Each Switch Bank will control one effects section.
LED Wire terminal blocks for quick connection
Board requires 9 Vdc @2 Amp Power supply
500 mA per channel output

Driver Board Size:
3-3/4" L x 2-1/2" W x 1/2" H

( Power supply, LED's not included )

500 mA per channel output

Unique board will control 24 LEDs by remote activation.
Board has input connection for remote activation by relays, switches or controller board.
Each Switch Bank will control 8 LED's, three switched banks available
LED Wire terminal blocks for quick connection
LED's require voltage drop resistance when connected to board.
Resistors not on control board.
Board requires 9 Vdc @2 Amp Power supply
500 mA per channel output

Driver Board Size:
3-3/4" L x 2-1/2" W x 1/2" H

( Power supply, LED's not included )

Unique board will control 3 High Intensity Luxeon LEDs by remote activation.
Board has input connection for remote activation by relays, switches or controller board.
Each Switch Bank will control one effects channel
LED Wire terminal blocks for quick connection
Board requires 9 Vdc @2 Amp Power supply

Driver Board Size:
3-3/4" L x 2-1/2" W x 1" H

( Power supply, LED's not included )

Unique board will control 2-Channels Switched On and Off Power Driver's by remote activation. The two channels can be connected to any standard Lighting Wire strands.
Board has input connection for remote activation by relays, switches or controller board.
Each Switch Bank will control one effects section
LED Wire terminal blocks for quick connection
Board requires 9 Vdc @2 Amp Power supply

Driver Board Size:
3-3/4" L x 2-1/2" W x 1" H

( Power supply, LED's not included )

Unique board will control 2-Channels Switched On and Off Power Driver's by remote activation. The two channels can be connected to any Fiber-optic Light source and fiber-optic cables.
Each Switch Bank will control one fiber section
Board has input connection for remote activation by relays, switches or controller board.
LED Wire terminal blocks for quick connection
Board requires 9 Vdc @2 Amp Power supply

Driver Board Size:
3-3/4" L x 2-1/2" W x 1/2" H

( Power supply, LED's not included )

Unique board will control 3-Channels Switched On and Off Power by remote activation. The three channels can be connected to any Light source such as LED's, LUXEON LED's, Fiber-optics, DC Light Bulbs.
Each Switch Bank will control one effects section, each effects section can operate 2 outputs (6 total outputs available)
Board has input connection for remote activation by relays, switches or controller board.
LED Wire terminal blocks for quick connection
Board requires 9 Vdc @2 Amp Power supply
500 mA per channel output

Driver Board Size:
2-1/2" L x 2-1/4" W x 1/2" HH

( Power supply, LED's not included )

BAT EYES

CAVE EYES

Bat Eyes:
Unique control board uses a PIC microcontroller to control a pair of red LED "eyes". The eyes are connected to 8" leads. There are 2 modes of operation ­ a dim-on and dim-off mode with controllable rate and a realistic random blink. The eyes go off when a sensor on the main board is illuminated. Great for sticking around in bushes for Halloween or in animatronic projects
PIC microprcessor on board - generated effects
Operates on 9 Volt battery. (Battery not included.)

Board Size:
1-7/8" L x 1-1/4" W x 5/8" H (w ithout battery )
3-5/8" L with Battery

Cave Eyes (8-Random blinking eye sets)
Control board uses a pre-programmed PIC microcontroller to control 8 pairs of water clear Red LED's "eyes". These eyes can be wired (user supplied, wire not included ) and located away from the main controller board, connected via small wire terminal block connections. The eyes blink randomly. Great for spreading around in a cave in haunted houses or any special effects projects.
PIC microprcessor on board - generated effects
Operates on 12Vdc.

Main Control Driver Board Size:
3" L x 1-1/4" W x 1/2" H

Mini LED Board Size: LED's-Water Clear RED
2-1/2" L x 3/8" W x 3/4" H

(12VDC power supply, Hook-up 24AWG twisted wire pair not included )

Instruction Manual

A unique programmable AC Voltage lighting dimmer controller. Board allows user to control a Solid State Dimmer (Crydom) that can control up to 20 Amps of AC voltage used in lighting or where variable AC Voltage is needed. There is a 4-Line by 16 Character back-lit LCD that is the user interface for programming the different modes of operation. There are 8 modes of operation available to the user. These modes are set up and initiated using a menu-driven display with input being made by 4 on board pushbuttons.
The board requires 12 to 24V DC @ 100 mA power supply.

Programmable Recording time - 10 Minutes
Some of the user modes include ramp up/down lighting Vdc full lighting on, power up and hold, variable programmable lighting effects and more.
Controller has remote trigger for remote activation,, onboard potentiomer to set and program variable lighting levels, Power On and Off switch, LED, sync port to trigger other boards connected. Wire terminal blocks, power jack for easy hook-up.
Programmable Master Controller and 20 Amp Solid-State Dimmer module included.

Controller can be used to operate character lighting units, stage lighting equipment, commercial special effects lighting and more.
Wire terminal blocks for connecting AC voltage source and load lines.
Max board output current is 15 Amp at 110-120 VAC.

Controller power supply, lighting devices not included

NOTE AC VOLTAGE CAUTION : This board uses AC voltage, care must be taken as AC voltage can cause serious injury and equipment damage if improperly used

This unique board will allow the control of eight Bi-Color LEDs. and effects.

There are 3 modes of operation that can be selected. In Mode 1, the LEDs are strobed on and off. In Mode 2, the LEDs are faded on and off. In Mode 3, the LEDs are either full on or off. The color of the LEDs is selected by dry contact closure of the Remote Green LED Trigger or the Remote Red LED Trigger terminals. There is also an on-board pushbutton that can be used to select the LED color. In Modes 1 and 2, when both triggers are activated simultaneously, the colors jump back and forth (Red / Green). In Modes 1 and 2, the rates of strobing or fading can be adjusted by using the Mode 1 or Mode 2 speed potentiometers. The rates at which the colors jump back and forth in Modes 1 and 2 is determined by the on-board potentiometers.
PIC microprcessor on board - generated effects

Board operates from 7-12 Vdc - Not Included

This unique board will allow the control of eight channels of remote DC lights (LED or incandescent) in 16 different sequences Each channel is capable of driving up to 200 mA of lighting. An on-board LED for each channel indicates that the channel is active. A 16-Position Mode Selection switch allows the user to select which sequence will be active. The selected sequence will begin immediately upon power-up and will continue until the power is removed from the board. There are 2 potentiometers on the board that allow the user to control the rate of the selected sequence.
The board has an on-board On/Off switch and a terminal block that allows the connection of a remote On/Off switch. Power can be supplied to the board via the 2.1mm power connector or the adjacent terminal block. Power should be provided that is sufficient to drive the board and all of the eight light channels (~2A max). There are 2 SS relays on the board that activate as soon as power is supplied to the board also for driving sound effect boards, or controller boards. PIC microprcessor on board - generated effects

Special Effect Operation:
Mode 1 ­ Marquee A: All channels start off. Channels 1 through 8 will then light up in sequence until all 8 channels are lit. Then all channels go off and then repeats.
Mode 2 ­ Marquee B: All channels start off. Channels 8 through 1 will then light up in sequence until all 8 channels are lit. Then all channels go off and then repeats (reverse of Mode 1).
Mode 3 ­ Marquee C: All channels start on. Then channels 1 through 8 will go off in sequence until all channels are off and then repeat.
Mode 4 ­ Marquee D: All channels start on. Then channels 8 through 1 will go off in sequence until all channels are off and then repeat (reverse of Mode 3).
Mode 5 ­ Cylon Effect: A single channel rasters back and forth.
Mode 6 ­ Reverse Cylon Effect: All channels are on with one channel being off that rasters back and forth (reverse of Mode 5).
Mode 7 ­ Knight Rider: All channels start off. Channels come on starting at channel 1 going to channel 8. When all channels are on, the channels begin turning off starting at channel 8 going down to channel 1.
Mode 8 ­ Strobe All: All channels strobe on and off in unison.
Mode 9 ­ Fade All: All channels will fade on and off in unison.
Mode 10 ­ Random Flash: Channels will flash randomly.
Mode 11 ­ Random Fade: Channels will randomly fade on and off.
Mode 12 ­ Heart Beat: All Channels will flash like a heartbeat. Rate Pot 1 will control the time between the 2 short flashes and Rate Pot 2 will control the overall rate of the heartbeat.
Mode 13 ­ Railroad Crossing Signal: Channels 1 ­ 4 and channels 5 ­ 8 will flash alternately.
Mode 14 ­ R2D2: Channels 1 ­ 4 will flash in unison at a rate controlled by Rate Pot 1. Channels 5 ­ 8 will flash in unison at a rate controlled by Rate Pot 2.
Mode 15 ­ Fireworks: Channels 1 through 7 will fade up and down in sequence. Then channel 8 will flash twice. Rate Pot 1 controls the rate of channel 1 ­ 7 and Rate Pot 2 controls the rate of the 2 flashes on channel 8.
Mode 16 ­ All On: All Channels on continuously.

( Power supply, LED's not included )

This unique board will allow use of a RC joystick or any wizard board servo output to control eight channels of remote DC lights (LED or incandescent) in 2 different sequences. Each channel is capable of driving up to 200 mA of lighting. An on-board LED for each channel indicates that the channel is active. Two on-board SS relays ­ one for each sequence - will also activate depending on which sequence is selected. A Mode Selection Switch will allow the user to toggle between Momentary On or Toggle On/Off modes. For example, with the Mode switched to Mode 1 (Momentary On), when the RC joystick is tilted to the left, Sequence 1 will start and Relay 1 will activate. Sequence 1 and Relay 1 will continue to be active as long as the joystick stays in the left position. When the joystick is in the center position, neither sequence will be selected. In Mode 2 (Toggle On/Off), when the joystick is tilted to the left and then returned to the center position, Sequence 1 will start and Relay 1 will activate. The sequence will continue and the relay will stay activated as long as the joystick remains in the center position. To stop this sequence, the user must tilt the joystick to the left a second time, toggling the sequence off. The same applies for Sequence 2. There are 2 potentiometers on board, one for each sequence that allows the user to control the rate of each sequence. The board has an on-board On/Off switch. Power to the board is supplied by the 5V line of the RC Servo connection and should have sufficient current to drive the board and all of the eight light channels (~2A max). PIC microprcessor on board - generated effects

Sequence 1 ­ Cylon Effect:
When the Joystick is tilted to the left, Relay 1 actuates and a single channel rasters back and forth. Rate 1 Potentiometers will control the rate of the rastering.

Sequence 2 ­ Strobe:
When the Joystick is tilted to the right, Relay 2 actuates and all channels strobe on and off in unison. Rate 2 Potentiometer will control the rate of the channel strobing.


( Radio Control System, R/C Receiver, Power supply, LED's not included )

Chroma Key Blue / Green Spray Paint is screen camera tested for video production.
Use on metal, wood, cloth, paper, plastics and foam

Available in 1 oz. can size

Due to D.O.T. regulations, this item can be shipped by ground transportation only.
Must be 21 year old to purchase.

A unique programmable AC Voltage lighting dimmer controller. Board allows user to control a Solid State Dimmer (Crydom) that can control up to 20 Amps of AC voltage used in lighting or where variable AC Voltage is needed. There is a 4-Line by 16 Character back-lit LCD that is the user interface for programming the different modes of operation. There are 8 modes of operation available to the user. These modes are set up and initiated using a menu-driven display with input being made by 4 on board pushbuttons.
The board requires 12 to 24V DC @ 100 mA power supply.

Programmable Recording time - 10 Minutes
Some of the user modes include ramp up/down lighting Vdc full lighting on, power up and hold, variable programmable lighting effects and more.
Controller has remote trigger for remote activation,, onboard potentiomer to set and program variable lighting levels, Power On and Off switch, LED, sync port to trigger other boards connected. Wire terminal blocks, power jack for easy hook-up.
Programmable Master Controller and 20 Amp Solid-State Dimmer module included.

Controller can be used to operate character lighting units, stage lighting equipment, commercial special effects lighting and more.
Wire terminal blocks for connecting AC voltage source and load lines.
Max board output current is 15 Amp at 110-120 VAC.

Controller power supply, lighting devices not included

NOTE AC VOLTAGE CAUTION : This board uses AC voltage, care must be taken as AC voltage can cause serious injury and equipment damage if improperly used

High Output LED's on vertical light boards attached to battery holders.
Modules have Power On / Off switches and 9Vdc battery holder attached to LED driver board.

Unit stands on end or can be set sideways.
LED's full ON when switched

Powered by 9 Vdc Battery

LED Colors Available
( Red, Green, Yellow, White, Blue )

Unit Size: 2-1/4" H x 1- 1/4" W x 1-1/4" D

( 9 Vdc battery not included )

High Output Specialized LED's on vertical boards attached to battery holders.
Module has Power On / Off switch and 9Vdc battery holder attached to LED driver board. Unit stands on end or can be set sideways.

Blinking LED's when switched On will Blink randomly

RGB LED's when switched On will flash - cycle between RGB colors flashes

LED - RGB ( Info on RGB LED )
LED - Blinking

Powered by 9 Vdc Battery

Unit Size: 2-1/4" H x 1- 1/4" W x 1-1/4" D
( 9 Vdc battery not included )

This board was designed to control 1-4 LED/ Fiber optic channels (user provided). There are 4 modes of operation. (1) Programmable, (2) Sequential ­ Timed, (3) Sequential ­ Triggered and (4) Random.

The user will be able to enter values for mode parameters via a menu-driven LCD that is attached to the main board by a 6' ribbon cable. All parameters are stored in non-volatile memory. Once the user has programmed in all parameters, they have the option of having the board go directly to running one of the modes upon board power-up.

Power to the board is via the 2.1 mm barrel connector or the adjacent terminal block. Playback is triggered by either pressing the Enter button or by dry contact closure at the remote trigger terminal. When the board is triggered to start playback, a 80 mS Sync Pulse is present at the Sync terminal.

Driver Board Size:
3-3/4" L x 2-1/2" W x 1/2" H

Fiber-Optic Cable

( Power supply, LED's Fiberoptic Cable not included )

Driver board will control two (2)12 VDC Light Bulbs or a string of LED's in an alternating (Back and Forth, like Rail Road Crossing Signal) Flashing effect

Board requires 12 VDC power supply
Output switching of board is 24 Watts (2 Amps) at 12 Vdc load
On board potentiometer to adjust alternating flash rate
Wire terminal block for 12VDC power connection
Wire terminal blocks for quick connection of LED/s or Light Bulbs
2-Amp per channel output

Board requires 12 Vdc @2 Amp Power supply

( Power supply, hookup wire, LED's / Light Bulbs, switch, enclosure box not included )

Driver board will control three (3)12 VDC Light Bulbs or a string of LED's in a sequence action of 1, 2, 3 repeating over and over effect. Flash rate can be adjusted by on-board potentiometer

Board requires 12 VDC power supply
Output switching of board is 24 Watts (2 Amps) at 12 Vdc load
On board potentiometer to adjust alternating rate
Wire terminal block for 12VDC power connection
Wire terminal blocks for quick connection of LED/s or Light Bulbs
2-Amp per channel output
Board requires 12 Vdc @2 Amp Power supply

( Power supply, hookup wire, LED's / Light Bulbs, switch, enclosure box not included )

Driver board will control three (3)12 VDC Light Bulbs or a string / block of LED's in a sequence action of 1, 2, 3. Board has 2 modes of operation:

AUTO
Board can be set to automatically sequence Lights 1,2,3 repeating over and over effect. Flash sequence rate can be adjusted by on-board potentiometer

MANUAL
With board in Manual mode, each time momentary switch is activated the next light in sequence will turn on and stay on until manually advanced to next light activated.

Board requires 12 VDC power supply.
Output switching of board is 24 Watts (2 Amps) at 12 Vdc load
On board potentiometer to adjust alternating rate.
Wire terminal block for 12VDC power connection.
Wire terminal blocks for quick connection of LED/s or Light Bulbs.
Wire terminal blocks for quick connection of Remote switches.

2-Amp per channel output
Board requires 12 Vdc @2 Amp Power supply.

( Power supply, hookup wire, LED's / Light Bulbs, switch, enclosure box not included )

Board accepts audio input from any non-amplified sound source (computer, CD player, or Digital Sound Board) and activates a Solid State Relay ON and OFF in sync with the incoming audio signal. The on-board 1 Amp Solid State Relay can be connected to any device using (3-60 Vdc @ 1 Amp power). Common application include driving a pneumatic solenoid valve, water valve to sound or operating large bank of LED's -DC lighting to the incoming sound.

There is an on-board potentiometer that is used to adjust the sensitivity to the incoming sound. The board has a 1/8" phono jacks for input that can be switched as a left or right audio input signal for more precision audio sync to incoming sound signal track.
